UL 1099 PVC电子线 HOOK-UP WIRE
说明 PRODUCT DESCRIPTION
●额定温度:80℃ ●额定电压:300V ●参考标准:UL758,UL1581 ●导体使用单支或绞合28AWG镀锡或裸铜 ●PVC绝缘,符合ROHS环保标准 ●通过UL VW-1、CSA FT1阻燃测试 ●绝缘厚度均匀、易裁线、易剥皮 |
●Rated temperature:80℃ ●Rated voltage:300V ●Reference standard:UL758,UL1581 ●Solid or stranded ,tinned or bare copper conductor 28AWG ●PVC insulation ,comply with ROHS environmental standard ●Passes UL VW-1,CSA FT1 flame test ●Uniform insulation thickness to ensure easy stripping and cutting |
应用 APPLICATION
●用于一般电子、电器设备内部连接线 ●For general purpose internal wiring of appliance.
■印字 MARKING
AWM 1099 ( )AWG 80℃ 300V VW-1 E****** CLEVER --- c AWM I A FTI 80℃ 300V()AWG -LF-
■产品结构 CABLE CONSTRUCTION
UL型号
UL STYLE |
导体 CONDUCTOR |
绝缘 INSULATION |
包装长度 PACKAGING LENGTH |
最大导体电阻 MAX.COND. RESISTANCE (Ω/km,20℃,DC) |
||||
线规 AWG |
线数/线径 No./mm |
外径 DIA. (mm) |
厚度 THICKNESS (mm) |
外径 O.D. (mm) |
英制 Ft/Coil |
公制 M/Coil |
||
UL1099 绞 线 (Stranded) |
28 |
7/0.127 |
0.38 |
0.40 |
1.20 |
2000 |
610 |
239 |
UL1099 先绞后镀 (Top-coated) |
28 |
7/0.127 |
0.38 |
0.40 |
1.20 |
2000 |
610 |
239 |
UL1099 单 支 (Solid) |
28 |
1/0.32 |
0.32 |
0.39 |
1.10 |
2000 |
610 |
227 |
conductor tolerance 单支导体公差:+/-0.005mm, wire tolerance导线外径公差:OD+/-0.10mm
以上仅供参考,详细规格按双方确认规格书为准。
