UL 1500 PVC连接线 HOOK-UP WIRE
说明 PRODUCT DESCRIPTION
|
●额定温度：105℃ ●额定电压：600V ●参考标准：UL758,UL1581 ●导体使用绞合26~10AWG镀锡或裸铜 ●SRPVC绝缘，符合ROHS环保标准 ●通过UL VW-1、CSA FT1阻燃测试 ●绝缘厚度均匀、易裁线、易剥皮 |
●Rated temperature：105℃ ●Rated voltage：600V ●Reference standard：UL758,UL1581 ●Stranded ,tinned or bare copper conductor 26~10AWG ●SRPVC insulation ,comply with ROHS environmental standard ●Passes UL VW-1,CSA FT1 flame test ●Uniform insulation thickness to ensure easy stripping and cutting |
应用 APPLICATION
●用于一般电子、电器设备内部连接线 ●Insulated Resistance Wire for Heating Cable Units
■印字 MARKING
AWM 1500 ( )AWG 105℃ 600V VW-1 E347813 CLEVER --- c AWM I A FT1 105℃ 600V （）AWG -LF-
■产品结构 CABLE CONSTRUCTION
|
UL型号
UL STYLE |
导体 CONDUCTOR |
绝缘 INSULATION |
包装长度 PACKAGING LENGTH |
最大导体电阻 MAX.COND. RESISTANCE （Ω/km,20℃,DC） |
||||
|
线规 AWG |
线数/线径 No./mm |
外径 DIA. (mm) |
厚度 THICKNESS （mm） |
外径 O.D. (mm) |
英制 Ft/Coil |
公制 M/Coil |
||
|
绞 线 (Stranded) |
26 |
7/0.16 |
0.48 |
0.80 |
2.10 |
2000 |
610 |
150 |
|
24 |
11/0.16 |
0.61 |
0.80 |
2.25 |
94.2 |
|||
|
22 |
17/0.16 |
0.76 |
0.80 |
2.40 |
59.4 |
|||
|
20 |
26/0.16 |
0.94 |
0.80 |
2.55 |
36.7 |
|||
|
18 |
41/0.16 |
1.18 |
0.80 |
2.80 |
23.2 |
|||
|
16 |
26/0.254 |
1.49 |
0.80 |
3.10 |
1000 |
305 |
14.6 |
|
|
UL1500 编织线 (Braided) |
18 |
24/3/0.12 |
0.45×2.55 |
0.80 |
2.25×4.80 |
1000 |
305 |
23.2 |
|
16 |
24/6/0.12 |
0.45×2.55 |
0.80 |
2.25×4.80 |
14.6 |
|||
conductor tolerance 单支导体公差：+/-0.005mm, wire tolerance导线外径公差：ＯＤ+/-0.10mm
以上仅供参考，详细规格按双方确认规格书为准。
