●额定温度：60℃,80℃

●额定电压：30V

●参考标准：UL758,UL1581

●导体使用单支或绞合最小40AWG镀锡或裸铜

●SR-PVC/PVC绝缘，符合ROHS环保标准

●镀锡或裸铜编织屏蔽

●PVC护套，符合ROHS环保标准

●通过UL VW-1、cUL FT1阻燃测试

●使用标准绝缘厚度、易裁线、易剥皮

●Rated temperature：60℃,80℃

●Rated voltage：30V

●Reference standard：UL758,UL1581

●Solid or stranded ,tinned or bare copper conductor 40AWG min.

●SR-PVC/PVC insulation , comply with ROHS environmental standard

●Tinned or bare copper wire braid shield

●PVC jacket , comply with ROHS environmental standard

●Passes UL VW-1、cUL FT1 flame test

●Uniform insulation thickness to ensure easy stripping and cutting

导体

CONDUCTOR

绝缘

INSULATION

屏蔽

SHIELD

排流线

DRAIN

编织

BRAID

护套

JACKET

规格

AWG

构造

CONSTR-

UCTION

(No./mm)

外径

DIA.

(mm)

芯数

(No)

绝缘厚度

INSULATION

THICKNESS

(mm)

外径

O.D.

(mm)

构造

CONSTRU-

CTION

构造

CONSTR-

UCTION

(No./mm)

构造

CONSTRU-

CTION

(No./No./mm)

护套厚度

JACKET

THICKNESS

(mm)

外径

O.D.

(mm)

30

7/0.10

0.30

10P

0.15

0.60

Al-mylar

7/0.10

16/8/0.10

0.65

5.40

15P

0.15

0.60

Al-mylar

16/8/0.10

0.65

6.20

18P

0.15

0.60

Al-mylar

16/8/0.10

0.70

6.70

19P

0.15

0.60

Al-mylar

16/8/0.12

0.75

7.00

25P

0.15

0.60

Al-mylar

16/8/0.12

0.75

7.70

28

7/0.127

0.38

10P

0.16

0.70

Al-mylar

7/0.127

16/8/0.10

0.65

6.00

15P

0.16

0.70

Al-mylar

16/8/0.10

0.75

7.15

18P

0.16

0.70

Al-mylar

16/8/0.10

0.75

7.60

19P

0.16

0.70

Al-mylar

16/8/0.12

0.75

7.85

25P

0.16

0.70

Al-mylar

16/8/0.12

0.85

8.80

26

7/0.16

0.48

3P

0.16

0.80

Al-mylar

7/0.16

16/6/0.10

0.65

4.40

6P

0.16

0.80

Al-mylar

16/8/0.10

0.65

5.50

9P

0.16

0.80

Al-mylar

16/8/0.12

0.70

6.50
